Technical data
Output power RMS / Max.

- @ 4 Ohms
Channels A - D: 4 x 65 Watts (min. 3 Ohms)
- @ 2 Ohms
-
- @ 1 Ohm
-
- bridged @ 4 Ohms
-
- bridged @ 2 Ohms
-
- Subwoofer output @ 4 Ohms
Kanal E - F: 2 x 90 Watts
- Subwoofer output @ 2 Ohms
Kanal E - F: 2 x 160 Watts
Amplifier technology
Class GD
Inputs
6 x Highlevel speaker input
1 x Optical SPDIF (12 - 96 kHz)
1 x MEC
1 x Remote In
Input sensitivity
2.8 - 11 Volts
Input impedance RCA / Cinch
-
Input impedance highlevel
9 - 33 Ohms with ADEP.3
Outputs
6 x Speaker output
1 x RCA / Cinch
1 x Remote Out
Output voltage RCA / Cinch
3 Volts RMS
Frequency response
10 Hz - 22,000 Hz
DSP resolution
64 Bit
DSP power
295 MHz (1.2 billion MAC operations/second)
Sampling rate
48 kHz
DSP type
Audio signal processor
Signal converters
A/D: BurrBrown
D/A: BurrBrown
Signal-to-noise ratio digital input
106 dB (A-weighted)
Signal-to-noise ratio analog input
104 dB (A-weighted)
Distortion (THD)
< 0.03 %
Damping factor
> 100
Operating voltage
10.5 - 18 Volts (max. 5 sec. down to 6 Volts)
Power rating
DC 12 V ⎓ 35 A max.
Idle current
360 mA
Max. remote output current
500 mA
Operating temperature range
-40 °C to +70 °C
Fuse
1 x 30 A LP-Mini-fuse (APS)
Additional features
Class GD technology with dynamically controlled
power supply, 32 Bit CoProcessor, ADEP.3 circuit, Start-Stop capability, Smart Control Port, USB, MEC slot, Auto Remote switch, galvanically isolated Line Out
Dimensions (H x W x D)
46 x 130 x 130 mm /
1.81 x 5.12 x 5.12
